Border Gateway Protocol (BGP) is an essential protocol for the Internet, responsible for exchanging routing information between autonomous systems (AS). However, its inherent vulnerabilities can lead to severe incidents, including route hijacking and DDoS attacks. This article outlines how to implement secure BGP routing on Linux servers, enhancing the robustness and resilience of network infrastructure.

Prerequisites

Before diving into BGP configuration, ensure you have:

  • A Linux server with a root or sudo access.

  • A BGP daemon (like Quagga or FRRouting) installed.

  • Basic knowledge of networking and BGP principles.

Installing BGP Daemon

For this article, we will install FRRouting, a popular open-source BGP routing daemon.

1. Update system packages:

bash
sudo apt update && sudo apt upgrade -y

2. Install FRRouting:

bash
sudo apt install frr

3. Enable FRRouting:

After installation, enable the FRRouting service:

bash
sudo systemctl enable frr
sudo systemctl start frr

Configuring BGP

  1. Edit the FRRouting Configuration File:

    The configuration file is usually located at /etc/frr/frr.conf. Open it with a text editor, like nano or vim:

    bash
    sudo nano /etc/frr/frr.conf

  2. Basic BGP Configuration:

    Add your BGP configuration block:

    plaintext
    router bgp
    bgp router-id
    neighbor remote-as
    …

    Replace <YOUR_AS_NUMBER>, <YOUR_ROUTER_ID>, <NEIGHBOR_IP>, and <NEIGHBOR_AS_NUMBER> with actual values.

  3. For Route Filtering and Policies:

    Implement prefix lists, route maps, and filter lists to ensure that only legitimate routes are propagated.

    plaintext
    ip prefix-list MY_PREFIX_LIST seq 5 permit masklen ge
    route-map MY_ROUTE_MAP permit 10
    match ip address prefix-list MY_PREFIX_LIST
    …

Implementing BGP Security Features

1. BGP Session Authentication

BGP can be vulnerable to session hijacking. To mitigate this, implement MD5 authentication for BGP sessions:

plaintext
neighbor password

2. TTL Security Check

Configure a TTL (Time to Live) security check, ensuring that packets originate from the correct source.

Add the following configuration:

plaintext
neighbor ttl-security hops

3. Configuring Route Filtering

Route filtering involves controlling which routes are accepted or advertised. Using prefix lists or AS path filtering can significantly enhance security by preventing route hijacking.

Example for AS path filtering:

plaintext
neighbor prefix-list in
neighbor prefix-list out

Validation with RPKI

Resource Public Key Infrastructure (RPKI) helps validate the authenticity of route announcements. You can configure RPKI on your BGP server to accept only those prefixes that are verified through RPKI.

  1. Install RPKI Software:

    Install an RPKI validator like rpki-client:

    bash
    sudo apt install rpki-client

  2. Configure RPKI with your BGP daemon:

    In your BGP configuration, add:

    plaintext
    bgp brk

Monitoring BGP Sessions

Monitoring is vital for maintaining a secure BGP setup. Use tools like bgpq3, bgpdump, and zebra to keep an eye on the health of your BGP sessions and the advertised routes.

Conclusion

Implementing secure BGP routing on Linux servers is an essential task for any network operator. By following best practices like session authentication, route filtering, and RPKI validation, you can significantly enhance the security of your BGP implementation.

Always stay updated with the latest security patches for your BGP daemons, as vulnerabilities can arise over time. Additionally, join relevant communities or forums for insights and guidance from peers.

With a carefully configured BGP setup, you can help ensure a more secure and resilient internet infrastructure.

Happy routing!
