In today’s connected world, the need for secure communication between remote offices and networks is paramount. A Site-to-Site Virtual Private Network (VPN) allows you to create a secure tunnel between two or more networks over the Internet. This blog post will guide you through the process of configuring a Site-to-Site VPN using OpenVPN on Linux servers.

Prerequisites

Before we begin, ensure you have the following:

  1. Two Linux servers: One will act as the VPN server and the other as the client. We’ll assume both servers are running Ubuntu.

  2. Root access: You’ll need administrative privileges to install packages and modify system configurations.

  3. Basic knowledge of Linux command line: Familiarity with terminal commands will help you through this guide.

Step 1: Install OpenVPN

First, log in to both servers and install OpenVPN along with the required utilities.

sudo apt update

sudo apt install openvpn easy-rsa -y

Step 2: Configure the Certificate Authority (CA)

After installation, you need to set up the Certificate Authority (CA) on the server that will act as your VPN server.

  1. Create a directory for the Easy-RSA files:

    make-cadir ~/openvpn-ca

cd ~/openvpn-ca

  2. Edit the vars file to set up the variables for your CA. Look for lines containing export KEY_COUNTRY, KEY_PROVINCE, and other details, and adjust them according to your location:

    nano vars

  3. Generate the CA:

    source vars

./clean-all

./build-ca

Step 3: Create Server and Client Certificates

Generate Server Certificate

  1. Generate the server certificate and private key:

    ./build-key-server server

  2. Generate Diffie-Hellman parameters:

    ./build-dh

  3. Generate HMAC key:

    openvpn --genkey --secret keys/ta.key

Generate Client Certificate

On the server, generate a certificate for the client:

./build-key client

Step 4: Configure OpenVPN on the Server

  1. Copy the example configuration file to the OpenVPN directory:

    sudo cp /usr/share/doc/openvpn/examples/sample-config-files/server.conf.gz /etc/openvpn/

sudo gzip -d /etc/openvpn/server.conf.gz

  2. Edit the OpenVPN configuration file:

    sudo nano /etc/openvpn/server.conf

    Modify the following lines (hold down Ctrl + W to search):

    • Uncomment and set the ca, cert, key, and dh lines to point to the correct certificate paths:

      ca /etc/openvpn/ca.crt

cert /etc/openvpn/server.crt

key /etc/openvpn/server.key

dh /etc/openvpn/dh2048.pem

    • Uncomment user nobody and group nogroup to run OpenVPN with non-privileged user privileges.

    • Set push "route <your_client_network> <subnet_mask>" to direct traffic to the client network.

  3. Start and enable the OpenVPN server:

    sudo systemctl start openvpn@server

sudo systemctl enable openvpn@server

Step 5: Configure OpenVPN on the Client

  1. Create a Client Configuration File:

    sudo nano /etc/openvpn/client.ovpn

    Paste the following configuration:

    client

dev tun

proto udp

remote [SERVER_IP] 1194

resolv-retry infinite

nobind

persist-key

persist-tun

ca ca.crt

cert client.crt

key client.key

remote-cert-tls server

tls-auth ta.key 1

cipher AES-256-CBC

verb 3

    Replace [SERVER_IP] with the public IP address of your server.

  2. Copy the necessary certificates: Make sure the necessary .crt and .key files are transferred to the client from the server.

Step 6: Start the Client VPN

  1. Start the OpenVPN client:

    sudo openvpn --config /etc/openvpn/client.ovpn

When successfully connected, you should see connection logs on both the server and client sides.

Step 7: Verify the Connection

To verify that the VPN is working:

  1. Check the IP address on the client to ensure it’s part of the VPN subnet:

    curl ifconfig.me

  2. Ping the VPN server from the client:

    ping [SERVER_VPN_IP]

Conclusion

You have now successfully set up a Site-to-Site VPN using OpenVPN on Linux servers! This configuration allows secure communication between your networks, ensuring that your data remains private and secure.

Resources

This article aims to provide a comprehensive yet straightforward guide for setting up your Site-to-Site VPN on Linux. For further customization and advanced configurations, be sure to refer to the OpenVPN documentation. Happy tunneling!
